Network IP Port setup: RemoteServer communicates with RemoteClient via two unique port numbers. When communication is established, data should appear in the LCD data window.
Butel software for scanners manual#
RemoteServer User Manual - BuTel software - 4ĥ Software Setup: Comport setup: In the software select the comport and baudrate and click APPLY. Comopen must be green status for Comdata status to become green. Comdata: Indicates whether there is communication with the scanner. Or another scanner is already using the comport selected. Comopen = red: Selected comport is either disabled or not available in your system. Comopen = green: If comopen indicator is green, the selected comport is available and the RemoteServer software succesfully opened the port. If you are running a single scanner version, ignore the status for scanners 2-4.
Butel software for scanners serial#
Checking Serial communication in STATUS window (select STATUS TAB in the software) : The Status panel displays comport status for all 4 scanners. use a different cable, 95% of com problems are caused by wrong or faulty serial cables.
Butel software for scanners driver#
Check the Windows device manager for any conflict in serial hardware - USB devices require a driver and comport number is selected in the windows device manager.
RemoteServer User Manual - BuTel software - 3Ĥ Serial communication problems: In case of serial communication problems, use this checklist: - Make sure comport is enabled in computer BIOS setup. Without additional soundcardsb the audio cannot be separated at the client. So a server with 4 scanners connected, requires 4 audio cards to stream separated audio. Also every scanner that you connect to the server requires an additional audio card. Important: USB devices always require a driver supplied by the manufacturer.
USB to serial converters, these are plugged in the USB connector at the back of the PC and output is a normal RS232 connector. For scanner 3 and scanner 4 additional hardware is required: we recommend one of the two following options: - PCI serial port extender card, these cards have 2 extra serial ports. Most PC motherboards have 2 serial port connections. If more than one scanner is used, additional hardware may be required. Connecting more than one scanner to the server: The Uniden BC785/796 use a standard RS232 serial port. Since streaming is mono a simple shielded cable can be used. These connectors use standard 1/8 mono or stereo connectors. RemoteServer User Manual - BuTel software - 2ģ Audio: Connect the external speaker output from the scanner to the line in connection at the sound card. Make sure that the scanner baud rate is set to 19200: - Turn scanner ON - Press MENU - Press 3 (system option) - Press 5 (Pc control) - Use arrow up/down and select and confirm by pressing E - Use MENU to leave menu, scanner is now set to baud rate. Make sure that scanner 1 is connected to the com 1 serial port etc. Connect a straight thru RS232 cable between the scanner and the DB9 serial port connector at your PC. At the back of the scanner you will find a DB9 connector, this is the remote control serial port.
RS232: RemoteServer works with the Uniden BC785 and BC796 scanners. if you do not have a static learn Info at: or RemoteServer User Manual - BuTel software - 1Ģ Connect the Scanner: Two connections must be made between the scanner and server: RS232 serial port and audio. Without this the clients are not able to connect to the server. STATIC IP - DNS server: The RemoteServer PC must have either a static IP address or DNS server software installed. This firewall software should be configured in such a way that it only allows traffic to/from the RemoteServer software. FIREWALL software: We strongly suggest running firewall software at the RemoteServer PC. Contact you system administrator so they can open these ports. Scanner over IP requires that certain ports are open for data/audio transfer. IMPORTANT: To use Scanner Over IP you must have access to firewalls and possibly cable/dsl modem setup (NAT routing options). Enter the registration code to unlock the software.
Butel software for scanners serial number#
Without this registration code the software will only work for 4 days after installation! Start the software and select FILE _ REGISTRATION, write down the serial number and the serial number to and a registration code will be ed back. Start software: Select START _ PROGRAMS _ BuTeL _ RemoteServer Registration: All copies of RemoteServer require a unique registration number.
Butel software for scanners install#
1 BuTeL Software - Scanner Over Ip - RemoteServer software July Software installation: Run setup.exe, software installer will install the RemoteServer software.
